MC9 + Compact Regulator

This premiere travel regulator packs maximum performance into minimum space. A true featherweight second stage, the compact is built from lightweight techno-polymers to eliminate jaw fatigue. Easy to pack and easy to dive, the compact includes dive/pre-dive venturi switch for managing freeflow and maximizing performance at depth

Technical Features

Technical features 1st stage:
– Balanced diaphragm (seal chamber for mc9sc)
– 2 outlets hp 7/16 unf
– 4 outlets mp 3/8 unf
– Service pressure: 300 bar (4350 psi) din version, 232 bar (3365 psi) yoke version
– Calibration pressure: 10 bar
– Brass body electroless nickel plated
– High capacity conical fi lter electroless nickel plated
– Aisi 316 removable nozzle
– Hyper-balancing
– Anti-pressure drop pneumatic spring
– Setting spring: stainless steel with micropeening treatment
– Replaceable cylinder with anti-friction and anti-corrosion properties
– Elastomer protector
– Flow rate: 4500 l/min
– Yoke version weight: 590 gr
– Din version weight: 450 gr

Technical features 2nd stage:
– Downstream system
– Adjustable venturi effect
– Patented antifriction lever
– Big purge button
– Anti-scratch surface
– Bayonet-type cap holder with security lock
– Removable exhaust tee without tools
– Weight without hose: 135 gr

Combination performance:
– Average cracking effort 6 mbar
– Average breathing effort 1 j/l
– Jacketed hose extremely light and flexible weight: 153 gr
– Certification en250/2014 A>10° c
